Universal Weld- On Parallel 4-Link Suspension Kit

Applications:

• Compatible with universal Rod Rat Trucks, Cars, and Air Ride systems

• Suitable for Classic Trucks and Cars with Air Ride setups or Coilovers

Features:

• Simplified installation with integrated bar mounts

• Flexible mounting options: beside the frame rail, inboard, or outboard

• Provides additional clearance for exhaust systems (no angled upper bars)

• Constructed from high-strength, corrosion-resistant steel

• Universal fit for various custom builds

Specifications:

• Placement: Rear, Left, Right

4-Link Bar Details:

• Tubing: 1.25" (31.75 mm) Outer Diameter, 0.156" (3.96 mm) Wall Thickness

• Bar Length: 24.00" (609.6 mm) center-to-center (fully adjusted in)

Package Includes:

• 4 × Heavy-Duty 24" (609.6 mm) Steel Bars

• 4 × Zinc-Plated Steel Rod Ends with Urethane Bushings

• 2 × Steel Weld-On Axle Mounts

• 2 × Steel Weld-On Frame Mounts

• 4 × Steel Weld-On Center Link Axle Mounts

• 10 × Hex Head Bolts with Nuts

• 1 × 24.00" (609.6 mm) Panhard Bar

• 1 × Weld-On Axle Mount for Panhard Bar

• 2 × Weld-On Frame Mounts for Panhard Bar

Warranty: 1- Year Manufacturer Warranty

Note: Depending on availability, these items can be provided in as little as a few days or may take a few weeks.
